FOTON Single Row Cargo Transport Truck With Fence Plate Style Carrying Goods Truck Freight Train

Condition : New

Steering : Left

Emission Standard : Euro 6

Brand Name : Foton

Place of Origin : Hubei, China

Segement : Light truck

Market Segement : Logistics transportation

Fuel Type : Diesel

Engine Capacity : < 4L

Cylinders : 4

Horsepower : < 150hp

Transmission Type : Manual

Forward Shift Number : 6

Reverse Shift Number : 1

Maximum Torque(Nm) : ≤500Nm

Cargo Tank Dimension : 4.17*2.1*0.4

Cargo Tank length : ≤4.2m

Cargo Tank Type : Fence

Gross Vehicle Weight : <=5000 kg

Capacity (Load) : 1 - 10t

Fuel Tank Capacity : ≤100L

Drive Wheel : 4X2

Passengers : 3

Driver's Seat : Normal

Seat Rows : Single row

Rear Camera : Camera

ABS(Antilock Braking System) : Yes

ESC(Electronic Stability Control System) : Yes

Touch Screen : None

Multimedia System : Yes

Window : Automatic

Tire Number : 6

After-sales Service Provided : Onsite Installation, Video technical support, Field installation, commissioning and training, Online support

Color : Customer's Request

Price : CN¥86,768.40/sets 1-17 sets

Contact Now

FOTON Single Row Cargo Transport Truck With Fence Plate Style Carrying Goods Truck Freight Train

Announcement model: BJ1048V9JEA-FM3
Type: truck
Driving form: 4X2
Wheelbase: 3360mm
Case length level: 4.2 m
Engine: Foton Cummins F2.5NS6B160
Gearbox: Fast F6JZ45AM
Rear axle speed ratio: 4.33
Body length: 5.995 meters
Body width: 2.2 m
Body height: 2.37 m
Front wheel base: 1725mm
Rear wheel base: 1615mm
Vehicle weight: 2.565 tons
Rated load: 1.735 tons
Total mass: 4.495 tons
Maximum speed: 105KM/h
Tonnage class: Light truck
Approach Angle: 20 degrees
Departure Angle: 16 degrees
Note: Standard: There are engine side fender, electronic accelerator pedal, DOC+DPF+SCR+ASC, 12L urea tank, flexible wind shield, maintenance-free battery, 1, 100A·h, aluminum transmission, φ260mm diaphragm spring clutch, hydraulic clutch control, vacuum clutch power, 1 spare tire, hydraulic power steering, circulating ball steering, non-through structure, no air reservoir, shoe wear alarm, ordinary vacuum booster, central drum parking brake, 2.7t, 250 single-stage reduction drive axle, Punch welding, no day light, no fog light, PP bumper, door open warning, forgotten key alarm, no seat belt not fastened alarm, internal rearview mirror, double overhead file cabinet, no B-post armrest, double sun visor, seat storage box, cup holder, map bag (door), no front downview mirror, intermittent multi-gear adjustable wiper, width 1730, Single row cab, rubber cab suspension, manual single torsion bar mechanical body flip, no hood, no deflector, side turn signal (door, no turn light), electric adjustment headlight, external antenna, cold and warm, fabric seat (luxury), halogen headlight. Optional: Electric power steering, no vacuum booster, day lights, fog lights, the main driver's seat belt is not tied alarm, there is a guide hood (no rear gap), no guide plate, side turn signal (door, with turn lights), heating and cooling. Electric air conditioning, with reversing radar (with main engine), with reversing buzzer, with cargo box accessories, driver seat belt height adjustable, passenger seat is not adjustable, central lock + electric window + remote control + electric, electric heating rearview mirror, central lock + electric window + remote control + manual adjustment, No external heating rearview mirror, front disc and rear drum, speed ratio 4.33, self-adjusting arm, automatic headlights, steel side protection, hydraulic power, 7-inch color screen instrument, LL6.50R16-10PR-NH, aluminum alloy rims, 14.5mm spoke, iron rim (7.25mm spoke), aluminum rim (14mm spoke), 7 inch MP5+ reverse image + Bluetooth function + navigation.
Front/rear overhang: 1.11/1.525 m
Engine parameter
Engine type: Foton Cummins F2.5NS6B160
Engine brand: Foton Cummins
Engine commonly known as: Falcon F2.5N
Number of cylinders: 4-cylinder
Fuel Type: Diesel oil
Cylinder arrangement: orthostitial
Displacement: 2.498 L
Emission standard: Kokuroku
Maximum output power: 115kw
Maximum horsepower: 160 horsepower
Maximum torque: 500N·m
Maximum torque speed: 1200-2200RPM
Rated speed: 2800RPM
Engine form: Electronic common rail system HEGR+DOC+DPF+SCR+ASC
Container parameter
Container form: panel
Container length: 4.17m
Container width: 2.1 m
Container height: 0.4 m
Cab parameter
Cab: FOTON
Cab width: 2060mm
Number of permitted passengers: Three people
Number of seats: Single row
Transmission parameter
Transmission model: Fast F6JZ45AM
Shift mode: AMT hands are one
Forward gear: Sixth gear
Number of reversals: one
Shell material: Aluminium alloy
Fuel tank
Fuel tank material: plastic
Tank capacity: 80L
Chassis parameter
Front axle allowable load: 1575KG
Rear axle description: 2.7
Rear axle allowable load: 2920KG
Speed Ratio: 4.33
Number of spring pieces: Three-quarters of + 2
tyre
Tire Specifications: 7.00R16LT 8PR
Tire Type: enhanced
Number of tires: six
Brake braking
Vehicle brake type: Air brake
Parking brake: Cutoff brake
Front wheel brake: Disc brake
Rear wheel brake: Drum brake
