Dongfeng High Pressure Cleaning Sewage Suction Truck 10 Wheel 15000liters

Product Categories

Hubei Runli Special Automobile Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Place of Origin : Hubei, China

Brand Name : SCS

Price : CN¥258,859.06/sets >=1 sets

Transmission Type : Manual

Condition : New

Emission Standard : Euro 3

Fuel Type : Diesel

Tank Volume : 15000L

Size : 9600*2490*3350

Horsepower : 251-350HP

Gross Vehicle Weight : 20-25T, 25000

After-sales Service Provided : Overseas Call Centers, Free spare parts, Onsite Installation

Capacity (Load) : 11 - 20T

color : optional

Chassis brand : Dongfeng Foton Forland Howo Faw

Function : High Pressure Dredging Jetting

Tank material : Q235 Carbon Steel

WHEELBASE : 4650+1300

Pump : Special Vacuum Pump

Drive type : 6x4

Engine : Cummins

Contact Now

Product Description

Dongfeng High Pressure Cleaning Sewage Suction Truck 10 Wheel 15000liters

tem	unit	parameter
Vehicle model		Dongfeng 6x4 Sewage Suction Truck
Chassis model		DFL1251GLJ5
Overall dimensions	mm	9600×2490×3350
Fact cubage	L	15000
Mass in working order	kg	Appro×11505
Body internal dimensions	mm	6000×1800(Length×diameter)
Wheel base		4350+1300
F/R track base		1940/1860
Approach/departure angle	°	28/15
Exhaust/kw	ml/kw	5900/155
Max speed	km/h	85
Tire specification	11.00R20	Engine type	B210-33
Traction system	6×4	transmission	6-speed with over drive
Number of axles	3	Electric system	24v
Operation control system	Electrically hydraulic control	Allowable passengers in cab	3
Equipment	Equipped with special vacuum pump(rating rotate speed=1400r/m,min rotate speed>800r/m, max suction lift>6m, vacuum>500mmHg, clockwise)
	Equipped with power take off, transmission shaft, high pressure sewage tank, pipe network, sewage pipe for observing and cleanout equipment
	Time for full sucktion<5min
Engine	DongFeng Cummins Environmental Protection, diesel engine,210 hp.
Production cycle	30-35 days
Warranty	12 month,from the date of supply
